Borger EL1550 pump Arjun Infrastructures’ WtE Plant.

Börger EL1550 Pumps at Arjun’s Waste-to-Energy Plant in London

We're pleased to bring readers the story of a genuinely unusual Waste to Energy application for the Börger EL1550 pump. Two of these robust rotary lobe pumps were engineered to circulate clean engine oil beneath the engine of a first-of-a-kind power plant in London — and getting them to perform in that space, at those temperatures, took some doing. Read on to see how Börger's pump experts solved the problem.

Börger EL1550 pump: the project at a glance

  • Site: Arjun Infrastructure's power plant in London, developed and managed by 2OC.
  • Output: 17MW of renewable energy generated from food waste, with the ability to use fats, oils and greases (FOG) — enough for approximately 40,000 homes.
  • The pumps: two Börger EL1550 Classic rotary lobe pumps, each driven by a 90kW motor, circulating clean engine oil.
  • The challenge: installed below ground, beneath the plant's engine, in a footprint of just 3m by 4m, under high temperatures and a non-negotiable deadline.
  • Main contractor: J. Murphy and Sons. Originally specified by: Jacobs Engineering.

Börger Press Feature (2020):

Pumps perfected for a first-of-a-kind plant to have the power to be its best

Exterior of Arjun Infrastructure's food-waste power plant in London where two Börger EL1550 pumps are installed.
Arjun Infrastructure's power plant in London, developed and now managed by 2OC.

Pumps for circulating clean engine oil — a reasonably ordinary application for Börger rotary lobe pumps? Perhaps. But then there's nothing ordinary whatsoever about Arjun Infrastructure's remarkable power plant in London, which generates 17MW of renewable energy from food waste and can also utilise fats, oils and greases (FOG).

“This is a first-of-a-kind plant,”

said Phil Jones, Director at 2OC, who developed the plant and now manages it on behalf of Arjun.

Two Börger EL1550 rotary lobe pumps mounted vertically on a custom base frame at Arjun's London power plant.
Börger's pumps at Arjun Infrastructure's power plant in London.

He added:

“Joining up assets that haven't previously been linked together before has presented many engineering challenges.”

Originally specified by Jacobs Engineering, the two 90kW lubrication pumps for the Combined Heat and intelligent Power (CHiP) plant had to be installed by main contractor J. Murphy and Sons in a very tight space — the first in a series of obstacles to be overcome.

Why the installation was so demanding

David Brown, from pump manufacturer Börger, explained:

“At first we thought that this was going to be a relatively uncomplicated job, but then the small footprint was just one of many hurdles to negotiate — not to mention the fact that the pumps had to go below ground, beneath the plant's engine.”

He added:

“We designed a special base frame so that the very robust Börger EL1550 Classic pumps could be mounted vertically into the small footprint (just 3m by 4m) — and then, for easy servicing, lifted out and put on their side. Over-pressure protection was required too. All a bit tricky, but often the case when there's not much space available.”

Producing enough energy for approximately 40,000 homes, Arjun's power station presents no shortage of high temperatures for its assets to cope with. This includes the Börger pumps, which had special cooling radiators for the gearboxes and motors installed.

A non-negotiable deadline

So far so good — but with the Börger pumps, and the demanding need to make all of the new power plant's equipment work together efficiently and economically, came a demanding, non-extendable deadline.

“We were fully aware of this from day one,”

continued 2OC's Phil Jones,

“…but I can't deny that the pressure was well and truly on. We had to meet the deadline for all-important government ROCs (Renewables Obligation Certificates) that support large-scale renewable electricity projects in the UK. To get the plant off on the right operational and financial footing, we had to make things happen to hit that deadline. We could not take our time.”

Solving the noise and vibration question

The construction contractors' engineers were initially concerned about the noise and vibration of the two Börger pumps. As everyone in the supply chain knows, this can be a delicate balance when both parties believe they are right.

“The Börger EL1550 Pumps were performing fine, but we were a little anxious at first,”

added Phil Jones.

“Failure wasn't an option.”

“For us,”continued David Brown from Börger,

“…we believed it was simply down to natural pulsation, but as well as going to site, we also brought over our top engineers from Germany. It didn't help us or 2OC that, due to the space limitations, the pipework for one pump was straight, whilst the other one was more complex and so had to cope with some pressure loss. Ultimately, we ran a test in Germany with 2OC in attendance to show that the pumps were performing fine. As it turned out, the vibration was down to nothing more than extra torque being required. Later, after another 500 hours of running time, an inspection confirmed that there were no issues. It has been a bit of a journey, but we always knew there was a reason, a solution.”

2OC's Phil Jones added:

“Börger were totally professional — taking our concerns very seriously to get to the bottom of this mystery. Through the very positive dialogue between the two companies, it was also decided to change the pump's removable rotor tips from rubber to a fully stainless-steel solid rotor design because of the high temperatures. Together with the stainless-steel pump-head, it now means that there is almost zero maintenance required.”

How the plant's energy and heat are used

Close-up of a Börger EL1550 rotary lobe pump at Arjun Infrastructure's waste-to-energy plant.Built by J. Murphy and Sons, Arjun's power plant sees 75GWh of the electricity sold to Thames Water for its Beckton sewerage processing plant (home to 64 Börger pumps), whilst the remaining 55GWh is purchased by Centrica.

Heat from the engine is supplied to the adjacent gas pressure reduction station owned by Cadent (with whom Börger also has pumps in a very important application), largely replacing old gas boilers that used to pre-heat the gas — whilst heat recovery cycles of the CHiP technology increase the thermal efficiency of the Arjun plant.

Phil Jones from 2OC concluded:

“Our pursuit of getting this unique power station where it needs to be has not been easy. But the plant is very much in line with the circular economy the UK government is promoting. We now have a very neat and efficient plant. This includes the Börger EL1550 Pumps, which are proving very efficient, reliable and easy to maintain thus far.”

This feature is based on a Börger press release, elements of which were also reported by the trade press — see Process Engineering, “Testing time pays off for power plant project” (10 September 2020).


What is the Börger EL1550 rotary lobe pump?

The Borger el1550 pump is one of the larger models in Börger's rotary lobe pump range. Rotary lobe pumps are positive displacement pumps: two counter-rotating lobed rotors move fluid steadily through the pump chamber, which makes them well suited to viscous, abrasive or variable media. For this project the EL1550 was handling clean engine oil, but the same principle makes the design popular in wastewater treatment, biogas, agriculture and industrial settings.

Two features made the EL1550 a good fit at Arjun's plant:

  • Maintenance in place (MIP): wearing parts can be accessed and replaced without disconnecting pipework — invaluable in a 3m × 4m underground space.
  • Configurable rotors and casing: the project team specified a solid stainless-steel rotor and stainless-steel pump-head to cope with high temperatures, reducing maintenance to a minimum.

You can see the current range on the Börger rotary lobe pumps pages.

Frequently asked questions

What is the Börger EL1550 pump used for?

The Börger EL1550 is a heavy-duty rotary lobe pump. At Arjun Infrastructure's London power plant, two EL1550 pumps circulate clean engine oil for the plant's engine. More broadly, Börger rotary lobe pumps are used to move viscous, abrasive and variable media across wastewater, biogas, agriculture and industrial applications.

Where is Arjun Infrastructure's London waste-to-energy plant?

It is located in London, close to Thames Water's Beckton sewerage processing works. The plant was developed and is managed by 2OC, and built by main contractor J. Murphy and Sons.

Drycake Twister food waste depackaging plastics separator
New Banner

How much energy does the plant generate?

According to the project team, the plant generates 17MW of renewable energy from food waste — enough for approximately 40,000 homes. Around 75GWh of electricity is sold to Thames Water for Beckton, with the remaining 55GWh purchased by Centrica.

Why were the pumps difficult to install?

The two 90kW EL1550 pumps had to sit below ground, beneath the plant's engine, in a footprint of just 3m by 4m, and cope with high temperatures. Börger designed a special base frame so the pumps could be mounted vertically and lifted out onto their side for servicing, with added cooling radiators and over-pressure protection.

Contact Börger Pumps 01902 798977

[Published July 2020. Updated November 20206.]
